Features

• Available sizes in 8″, 14″, 18″, 24″ & 33″ sizes with “N” no of plates as per requirement.
• Tentative Flow rate in Ltrs/Hr as per size : 400, 1500, 5500,9000,, 15000 respectively
• of Plates available: 8”x 4,6,8; 14”x 10,12; 18”x10,12,15,18; 24”12,15,18,23; 33” x 10,14,23 No. of plates
• Range Flow rate in Ltrs/Hr as per size: 300-500; 700-2000; 2500-6000; 6500-9000; 8000-20000 respectively. Flow rate will vary with every fluids viscosity.
• Attached Gear or centrifugal feed pump as per requirement.
• O.C.: SS-304, 316, 316L offered as per requirement.
• SS 304 jacket for hot filtration on request.
• With back wash facility for cleaning without opening the filter assembly & FLP motor offered on request.
• Used For filtration in sugar, beverage, food, Pharma, cosmetics, chemical, dyes, edible & non-edible, beverage, resins, paints & allied industries.

Maximum Working pressure 2 Kg/sq.cm
Maximum Working Temperature: 100-200 Degree celcius
